Wall Mount Pro Series

Model 6170H

Wall Mount - 6170H

Genie's Model 6170H features our wall mount design plus the integrated Aladdin Connect. This garage door opener eliminates the traditional rail & powerhead design by attaching directly to the garage door’s spring tube. Eliminating the rail & opener from the ceiling brings a clean and open look to your garage. Enjoy the view or use the freed-up space for storage or other purposes. This is ideal for garages with beam obstructions that prevent the installation of a traditional opener. The compact design fits into tight side room spaces.

24 Volt Motor
Aladdin Connect Smart Tech built in- works with Alexa
Battery Backup add on available (not included)
Wireless Wall Console
Holds up to 64 remotes
Flexible Placement LED Light Fixture
Door Lock Included
Limited Lifetime Warranty
HomeLink® & Car2U® compatible (No external repeater box or bridge needed.)

Special Features

Explore this helpful checklist to discover why Genie is the brand you trust, featuring our innovative Child Guard Battery Lock design and more.
The wall mount style clears up ceiling space by eliminating rail & powerhead from the ceiling. You can use the freed-up space for extra storage or just enjoy the clean, uncluttered look.
Aladdin Connect – Integrated smart garage capability provides the ability to remotely monitor & control your garage door with your smart device from almost anywhere at any time while tracking the operation of your door. Since Aladdin Connect is built into the opener, you do not need to add any other hardware. Works in conjunction with your home router.

Durable, reliable performance – The strong DC motor operates most properly balanced residential sectional doors up to 10' high and 500 pounds. Model 3120 has an opening speed of 7.0" per second.†
Safe-T-Pulse™ System – Patent-pending system that provides internal tension monitoring of door cables with an electronic pulse during initial door travel.
Bright LED light fixture provides ample glowing light with the flexibility to place fixture wherever desired in the garage.
Includes Door Lock which ensures no one can open the door from the outside without first pulling the release handle on the inside.
The 6170H is backed by a Limited Lifetime Warranty** for the motor.
